Marine PC

General

    Totem’s DNV type-approved Marine PC has been developed to provide reliable means in which to run the critical applications required on board all modern ships and vessels. Suitable for everyday functionality, Totem’s PC exhibits high performance and expandability. In addition, its “marine kit”- a sturdy shelf, shock absorbers, secure fasteners, and an EMC filter – have been designed to withstand vibration, mechanical shock, low/high temperature, humidity, and electromagnetic interference, which constitute some of the main factors associated with the extreme harshness of marine environments.





Specifications

  • IEC 945 / 60945 approved
  • 12xUSB 2.0/4xPCI/3xPCIe
  • 4 RS232 Serial ports
  • 2 PS/2 ports for keyboard and mouse
  • Core 2 Quad / Core 2 Duo / Pentium Dual Core / Celeron processors (Standard is Core 2 Duo 2.8GHz 1066MHz FSB)
  • 2x Gigabit LAN
  • Hard Disk SATA II up to 2 Terra byte (standard is 500Gb)
  • RAM up to 4 Gb (2Gb is standard) DDR2 800 MHz
  • Onboard VGA interface with Resolution up to 1800×1440@85Hz
  • DVD RW SATA II
  • Industrial Power Supply 450VA 115-230V
  • Watchdog timer
